BLS-M86-1
BLS
90278990
I. Application
The instrument is designed and manufactured according to the requirements of ASTM D86, and the People's Republic of China standard GB/T6536 Petroleum Product Distillation Measurement Method, applicable to determine the distillation characteristics of gasoline, aviation gasoline, jet
fuels, special boiling point solvent, naphtha, diesel oil, distillate and similar petroleum products.
II.Features
1.Control mode: PID system temperature control, digital display control cold bath temperature, temperature control accuracy is high.
2.Heating electric furnace wire using quartz glass tube encapsulation, no open fire, safe and reliable, long service life.
3.The power of the electric furnace is adjusted by the solid-state voltage regulator, which is continuously adjustable from low to high.
4.With electric furnace adjusting knob, it can easily adjust the best position of distillation flask.
5.New refrigeration compressor (steam diesel general type), electric stirrer composed of constant temperature bath, bath temperature uniform.Technical parameters
III.Technical Parameters
Temperature control range | 0 ~ 80℃ arbitrary setting |
Temperature control accuracy | ±0.1 ℃ |
Electric furnace movable plate | silicon carbide plate |
Power | 1.5KW |
Refrigeration system | new refrigeration compressor, refrigeration system warranty for 2 years (steam diesel general type) |
Power supply | AC220V± 10% 50Hz |
Ambient temperature | 5℃ ~ 40℃ |
Relative humidity | ≤ 85% |
Dimension(L*W*H) | 65*54*70cm |
Weight(Kg) | 45Kg |
