SX-150
SHATON
90278990
I.Application
Portable octane analyzer complies to ASTM D2699 and ASTM D613, applicable for instant octane and cetane rating of motor gasoline, corresponding to motor and research methods (RON and MON) as well as for cetane and octane number of diesel fuels. In addition for an inquiries, temperature rating of the analyzed liquid and diesel fuel solidification is provided. The results of measuring are displayed on the LCD.
II.Standards:
Determining octane numbers for motor petrols. Complies with ASTM D 2699-86, ASTM D 2700-86.
Determining cetane numbers for diesel. Complies with ASTM D 4737-03, ASTM D 613, EN ISO 5165.
Determining solidification temperature and diesel fuel type.
Content of pour-point depressants for diesel fuels. Content of kerosine in diesel fuel.
Petrol breakdown time (oxidative stability). Complies with ASTM D 525.
III.Operation Principle
The operational principle of the Octane Meter lies in gasoline octane rating and diesel fuel cetane rating based on the analysis of change of properties of an dielectric permeability and electromagnetic induction.
IV.Features
Octane analyzer has the portable compact design and is used for on-line inspection of motor fuel quality in the field and laboratory conditions. The operating conditions of the Octane analyzer usage: ambient temperature from – 10C to +30C, relative humidity 80% at 25 C, atmosphere pressure 84-106kPa. The device gets power from DC elements of type AA (supply
voltage 6V).
V.Technical Parameters
Types of controlled fue | all types of gasoline |
Range of measured octane level | 40-120 |
Range of measured cetane level | 20-100 |
Measurement inaccuracy of octane number | 0.5 |
Measurement inaccuracy of cetane number | 1 |
Data display | digital |
Time of measurement | below 10s |
Consumption current | 30mA |
Time of continuous running with one set of batteries | 100hours |
Operation temperature range | -10℃to +40℃ |
Relative humidity | 30% to 80% |
Atmosphere pressure | 64-106kPascal |
Dimensions | Sensor:60×100mm |
electronic module | 100 х 210 х 25mm |
Weight | 680g |
Mean-time-between-failures | >1000 |
